Advantech EKI-1521 1-Port Serial Device Server, 1x RS-232/422/485, 2x RJ45 Ethernet, 10/100Mbps, 12-48V DC

PART NO: EKI-1521-CE / SKU: 1032392
Advantech EKI-1521 1-Port Serial Device Server, 1x RS-232/422/485, 2x RJ45 Ethernet, 10/100Mbps, 12-48V DC
$506.00
inc. GST
$460.00
ex. GST
Free shipping on orders over $100

Discover the robust features of the Advantech EKI-1521-CE, a reliable 1-Port Serial Device Server.

  • Connects one RS-232/422/485 serial device.
  • Equipped with two RJ45 Ethernet ports for 10/100Mbps connectivity.
  • Operates on a versatile 12-48V DC power input.

Ensure seamless and efficient device networking with this advanced Advantech serial device server.

Product Specification

Brand:
Advantech
Type:
Serial Device Server
Width:
42 mm
Wattage:
3.2 W
Humidity:
10 to 95 %
IP Rating:
IP30
Protocols:
ICMP;IP;TCP;UDP;BOOTP;DHCP;Auto IP;SNMP;HTTP;DNS;SMTP;ARP;NTP
Model/Series:
EKI
I/O Port Type:
RJ45
Mounting Type:
DIN Rail Mount;Wall Mount
Rated Voltage:
12 to 48 V DC
Certifications:
CE;cUL;RoHS;FCC;IEEE
Connection Type:
DB9
Number of Ports:
1
Status Indicator:
Yes
Connection Gender:
Male
Transmission Speed:
10/100 Mbps (RJ45);50 to 921.6 kbps (Serial)
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-10 °C
Depth:
95 mm
Height:
140 mm
Weight:
432 g

Warranty Information

5 Years

Product Downloads

Datasheet
