Advantech EKI-1221 1-Port Modbus Gateway, 1x RS-232/422/485 Serial, 2x RJ45 Ethernet, 10/100Mbps, 12-48V DC

PART NO: EKI-1221-CE / SKU: 1032357
Advantech EKI-1221 1-Port Modbus Gateway, 1x RS-232/422/485 Serial, 2x RJ45 Ethernet, 10/100Mbps, 12-48V DC
$620.40
inc. GST
$564.00
ex. GST
Free shipping on orders over $100

Discover the Advantech EKI-1221-CE, a robust and versatile 1-Port Modbus Gateway designed for seamless industrial communication.

  • Equipped with one RS-232/422/485 serial port for flexible connectivity.
  • Features two RJ45 Ethernet ports with 10/100Mbps speeds for reliable network integration.
  • Supports a wide power input range of 12-48V DC, suitable for various industrial applications.

Enhance your industrial network with the reliable and high-performance Advantech EKI-1221-CE Modbus Gateway.

Product Specification

Brand:
Advantech
Type:
Modbus Gateway
Width:
36.6 mm
Wattage:
3.2 W
Humidity:
10 to 95 %
IP Rating:
IP30
Protocols:
ICMP;IP;TCP;UDP;BOOTP;DHCP;Auto IP;SNMPv1/v2/v3;HTTP;DNS;SMTP;ARP;NTP;HTTPS (TLS 1.3);IPv6;SSDP;Telnet;SSH
Model/Series:
EKI-1221
I/O Port Type:
RJ45
Mounting Type:
DIN Rail Mount;Wall Mount
Rated Current:
0.7 A @ 24 V
Rated Voltage:
12 to 48 V DC
Certifications:
KC;CE;cUL;RoHS;IEC;EN;FCC
Connection Type:
DB9
Number of Ports:
1
Connection Gender:
Male
Ethernet Standard:
IEEE 802.3;802.3ab;802.3u
Transmission Speed:
10/100 Mbps (RJ45)
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-10 °C
Depth:
95 mm
Height:
140 mm
Weight:
472 g

Warranty Information

5 Years

Product Downloads

Datasheet
