Advantech ADAM-6017 8-ch Isolated Analog Input Modbus TCP Module with 2-ch Digital Output

PART NO: ADAM-6017-D / SKU: 1032215
Advantech ADAM-6017 8-ch Isolated Analog Input Modbus TCP Module with 2-ch Digital Output
$666.60
inc. GST
$606.00
ex. GST
Free shipping on orders over $100

Discover the versatile capabilities of the Advantech ADAM-6017-D, an 8-channel isolated analog input module with Modbus TCP.

  • Features 8-channel isolated analog input for accurate data acquisition.
  • Includes 2-channel digital output for enhanced control.
  • Utilizes Modbus TCP protocol for seamless integration into existing systems.

Experience reliable and efficient data monitoring with this advanced Advantech module.

Product Specification

Brand:
Advantech
Type:
Ethernet IO Module
Wattage:
300 mW
Accuracy:
±0.10 %
Protocols:
Modbus TCP;TCP/IP;UDP;HTTP;DHCP Client;MQTT;SNMP;ASCII Command
Span Drift:
±25 ppm/°C
Zero Drift:
±6 μV/°C
Model/Series:
ADAM-6000
Sampling Rate:
100 S/S
Certifications:
KC;CE;FC;UL;RoHS
Interface Type:
Ethernet
Connection Type:
Plug In
Input Impedance:
10 MΩ
Input Voltage DC:
10 to 30 V DC
Input Signal Type:
V;mV;mA
Display Resolution:
16 bit
Number of Channels:
10
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-40 °C

Product Downloads

Datasheet
