Advantech ADAM-6015 7-Channel Isolated RTD Input Modbus TCP Module, 10-30V DC, TS 35 DIN Rail Mount

PART NO: ADAM-6015-DE / SKU: 1032214
Advantech ADAM-6015 7-Channel Isolated RTD Input Modbus TCP Module, 10-30V DC, TS 35 DIN Rail Mount
$784.30
inc. GST
$713.00
ex. GST
Free shipping on orders over $100

Discover the Advantech ADAM-6015-DE, a high-performance 7-Channel Isolated RTD Input Modbus TCP Module.

  • Equipped with 7 isolated RTD input channels for accurate readings.
  • Features Modbus TCP for reliable communication.
  • Designed for TS 35 DIN Rail Mount and operates on 10-30V DC.

Ensure precise and isolated temperature monitoring in industrial applications with the Advantech ADAM-6015-DE.

Product Specification

Brand:
Advantech
Type:
Ethernet Remote I/O Module
Wattage:
2.5 W
Accuracy:
±0.1 %
Protocols:
Modbus/TCP;TCP/IP;UDP;HTTP;DHCP
Span Drift:
±25 ppm/°C
Zero Drift:
±6 μV/°C
Sampling Rate:
1K S/S
Certifications:
IC;CE;FCC;UL;RoHS
Interface Type:
Ethernet
Connection Type:
Screw Terminal
Input Impedance:
>10 MΩ
Input Voltage DC:
10 to 30 V
Input Signal Type:
PT100;PT1000;Balco 500;Ni 518
Display Resolution:
16 bits
Number of Channels:
7
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-40 °C

Product Downloads

Datasheet
