Advantech ADAM-4572 1-Port Modbus Gateway, 1x RS-232/422/485 Serial, 1x RJ45 Ethernet, 10/100Mbps, 10-30V DC

PART NO: ADAM-4572-CE / SKU: 1032178
Advantech ADAM-4572 1-Port Modbus Gateway, 1x RS-232/422/485 Serial, 1x RJ45 Ethernet, 10/100Mbps, 10-30V DC
$645.70
inc. GST
$587.00
ex. GST
Free shipping on orders over $100

Discover the Advantech ADAM-4572 1-Port Modbus Gateway, a reliable solution for your industrial communication needs.

  • Seamlessly convert between RS-232/422/485 serial and RJ45 Ethernet.
  • Supports 10/100Mbps Ethernet for high-speed data transfer.
  • Operates with a flexible 10-30V DC power input.

Enhance your system's connectivity with the Advantech ADAM-4572-CE.

Product Specification

Brand:
Advantech
Type:
Modbus Gateway
Width:
70 mm
Wattage:
2.5 W
Humidity:
5 to 95 %
IP Rating:
IP30
Protocols:
Modbus;ASCII Command;RTU
Model/Series:
ADAM-4572
I/O Port Type:
RJ45
Mounting Type:
DIN Rail Mount;Wall Mount
Rated Current:
0.3 A @ 12 V
Rated Voltage:
10 to 30 V DC
Certifications:
KC;CE;EN;FCC;RoHS
Connection Type:
Plug In
Number of Ports:
1
Ethernet Standard:
IEEE 802.3;IEEE 802.3u
Transmission Speed:
10/100 Mbps (RJ45)
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-10 °C
Depth:
25 mm
Height:
112 mm
Weight:
125 g

Warranty Information

5 Years

Product Downloads

Datasheet
