Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal Block
Width:
6.5 mm
Colour:
Blue
Function:
Single Level Feed Through
Material:
PA 66
Blade Size:
0.6 x 3.5 mm
Cable Size:
26 to 12 AWG
Model/Series:
SAK
Mounting Type:
TS35 Rail Mount
Rated Current:
32 A
Rated Voltage:
800 V
Certifications:
CCCEX;CE;CSA;DNV;Ex I;IEC ExTUEV;Lloyds Register;UR;RoHS
Connection Type:
Screw
Number of Levels:
1
Stripping Length:
12 mm
Max Clamping Range:
6 mm²
Min Clamping Range:
0.13 mm²
Wire Cross Section:
4 mm²
Connection Direction:
Right
Number of Connections:
2
Max Operating Temperature:
+100 °C
Min Operating Temperature:
-50 °C
Depth:
44 mm
Height:
45 mm
Weight:
7.999 g
Model Part Code:
SAK 4/35 BL
