Product Specification
Brand:
Weidmuller
Type:
Feed Through Terminal
Width:
5.10 mm
Colour:
Dark Beige
Function:
Multi Level Feed Through
Material:
Wemid
Blade Size:
0.60 x 3.50 mm
Cable Size:
28 to 12 AWG
Model/Series:
A
Mounting Type:
TS35 Rail Mount
Rated Current:
22 A
Rated Voltage:
800 V AC/DC
Certifications:
CCC;CE;CSA;cURus;cURusEX;IECEx;DNA;KEMA;KEUR;ATEX;UKCA-EX;UR E60693;RoHS;UL;UKCA
Connection Type:
Push In
Number of Levels:
3
Stripping Length:
10 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.14 mm²
Wire Cross Section:
2.50 mm²
Connection Direction:
Right
Number of Connections:
6
Max Operating Temperature:
+130 °C
Min Operating Temperature:
-60 °C
Depth:
64.50 mm
Height:
116 mm
Weight:
20.70 g
Model Part Code:
A3T 2.5
