Product Specification
Brand:
Weidmuller
Type:
Component Terminal Block
Width:
5.1 mm
Colour:
Dark Beige
Function:
Double Level Feed Through
Material:
Wemid
Blade Size:
0.6 x 3.5 mm
Cable Size:
26 to 14 AWG
Model/Series:
WDK
Mounting Type:
TS35 Rail Mount
Rated Current:
0.5 A
Rated Voltage:
400 V
Certifications:
CE;UKCA;RoHS
Connection Type:
Screw
Number of Levels:
2
Stripping Length:
10 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.05 mm²
Wire Cross Section:
2.5 mm²
Connection Direction:
Right
Number of Connections:
4
Max Operating Temperature:
+120 °C
Min Operating Temperature:
-50 °C
Depth:
62.5 mm
Height:
69 mm
Weight:
12.63 g
Model Part Code:
WDK 2.5/D/3
