Weidmuller MOS Solid-State Relay, 1 NO Contact, 24V DC Control, 5-33V DC Switching, 10A, TS 35 Mount

PART NO: 8937940000 / SKU: 1017093
Weidmuller MOS Solid-State Relay, 1 NO Contact, 24V DC Control, 5-33V DC Switching, 10A, TS 35 Mount
$94.99
inc. GST
$86.35
ex. GST
Free shipping on orders over $100

Check out the Weidmuller MOS Solid-State Relay (8937940000), a high-performance solution for reliable switching applications.

  • Features 1 NO contact for efficient control.
  • Operates with 24V DC control and 5-33V DC switching at 10A.
  • Designed for convenient TS 35 mount installation.

Ensure robust and efficient power management with this advanced Weidmuller solid-state relay.

Product Specification

Brand:
Weidmuller
Type:
Solid State Relay
Width:
6.1 mm
Colour:
Black
Length:
97.8 mm
Wattage:
400 mW
Function:
Protection
Frequency:
50 Hz
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 V DC
Model/Series:
MOS
Release Time:
700 µs
Mounting Type:
DIN Rail Mount
Rated Current:
10 A
Rated Voltage:
5 to 33 V DC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Flexible Conductor
Operating Time:
250 µs
Connection Type:
Screw
Control Voltage:
24 V DC
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1NO
Protective Circuit Type:
Varistor
Rated Switching Current:
10 A
Rated Switching Voltage:
5 to 33 V DC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-20 °C
Height:
88.1 mm
Weight:
38.81 g
Model Part Code:
MOS 24VDC/5-33VDC 10A
