Product Specification
Brand:
Weidmuller
Type:
Fuse Terminal
Width:
8.10 mm
Colour:
Beige
Function:
Double Level Feed Through
Material:
Polyamide 66
Fuse Type:
G-Si. 5 x 20
Blade Size:
0.60 x 3.50 mm
Cable Size:
22 to 12 AWG
Model/Series:
SAK
Mounting Type:
TS35 Rail Mount
Rated Current:
6.30 A
Rated Voltage:
500 V AC/DC
Certifications:
CE;CSA;DNA;UKCA;UL;UR E60693;RoHS
Connection Type:
Screw
Number of Levels:
2
Stripping Length:
9 mm
Max Clamping Range:
4 mm²
Min Clamping Range:
0.33 mm²
Wire Cross Section:
4 mm²
Connection Direction:
On Side
Number of Connections:
4
Max Operating Temperature:
+100 °C
Min Operating Temperature:
-50 °C
Depth:
55.60 mm
Height:
76.50 mm
Weight:
20.07 g
Model Part Code:
KDKS 1/35
