IDEC RR2P General Purpose Relay, DPDT, 10A, 24V AC Coil, 8-Pin, Plug-In, with LED Indicator

PART NO: RR2P-UAC24V / SKU: 1002601
IDEC RR2P General Purpose Relay, DPDT, 10A, 24V AC Coil, 8-Pin, Plug-In, with LED Indicator
$49.72
inc. GST
$45.20
ex. GST
Free shipping on orders over $100

Discover the Idec RR2P General Purpose Relay, a versatile and reliable solution for your electrical needs.

  • Features a DPDT configuration for double pole, double throw switching.
  • Rated for 10A current and operates with a 24V AC coil.
  • Designed as an 8-pin, plug-in relay with a convenient LED indicator for easy status monitoring.

Ensure dependable performance and easy installation with this high-quality Idec relay.

Product Specification

Brand:
Idec
Type:
Power Relay
Width:
28.6 mm
Colour:
Transparent
Length:
55.5 mm
Wattage:
1.5 W
Frequency:
50/60 Hz
Coil Voltage:
24 V AC
Model/Series:
RR
Release Time:
25 ms
Mounting Type:
Socket Mount
Rated Current:
10 A
Rated Voltage:
240 V AC
Terminal Type:
Pin Terminal
Certifications:
cURus;CSA;TUV;CE
Operating Time:
25 ms
Connection Type:
Pin Terminal
Control Voltage:
24 V AC
Mechanical Life:
10000000 cycles
Contact Material:
Silver
Number of Contacts:
2
Contact Configuration:
DPDT
Rated Switching Current:
10 A
Rated Switching Voltage:
240 V AC;30 V DC
Max Operating Temperature:
+40 °C
Min Operating Temperature:
-25 °C
Height:
35.6 mm
Weight:
90 g

Product Downloads

Datasheet
