IDEC RH4B General Purpose Relay, 4PDT, 10A, 110V DC Coil, 14-Pin, Plug-In, with LED Indicator

PART NO: RH4B-UDC110 / SKU: 1002552
IDEC RH4B General Purpose Relay, 4PDT, 10A, 110V DC Coil, 14-Pin, Plug-In, with LED Indicator
$62.70
inc. GST
$57.00
ex. GST
Free shipping on orders over $100

Discover the high-performance IDEC RH4B General Purpose Relay (RH4B-UDC110), designed for reliable electrical control.

  • Features a 4PDT configuration, offering versatile switching capabilities.
  • Rated for 10A, ensuring robust power handling for various applications.
  • Equipped with a 110V DC Coil and LED indicator for clear operational status.

Enhance your systems with the durable and efficient IDEC RH4B General Purpose Relay.

Product Specification

Brand:
Idec
Type:
Power Relay
Width:
41 mm
Colour:
Transparent
Length:
27.5 mm
Wattage:
1.5 W
Test Button:
No
Coil Voltage:
110 V DC
Model/Series:
RH
Release Time:
25 ms
Mounting Type:
Socket Mount
Rated Current:
10 A
Rated Voltage:
240 V AC
Terminal Type:
Blade Terminal
Certifications:
cURus;CSA;TUV;CE
Operating Time:
25 ms
Connection Type:
Blade Terminal
Control Voltage:
110 V DC
Mechanical Life:
50000000 cycles
Contact Material:
AgCdO
Status Indicator:
Yes
Number of Contacts:
4
Contact Configuration:
4PDT
Rated Switching Current:
10 A
Rated Switching Voltage:
240 V AC;30 V DC
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Height:
35.6 mm
Weight:
74 g

Product Downloads

Datasheet
