Weidmuller TOS Solid-State Relay, 1 NO Contact, 24-230V UC Control, 24-240V AC Switching, 1A, DIN Rail Mount

PART NO: 1127500000 / SKU: 1029617
Weidmuller TOS Solid-State Relay, 1 NO Contact, 24-230V UC Control, 24-240V AC Switching, 1A, DIN Rail Mount
$99.68
inc. GST
$90.62
ex. GST
Free shipping on orders over $100

Discover the Weidmuller TOS Solid-State Relay (1127500000), a versatile and reliable solution for your control and switching needs.

  • Features a 1 NO Contact for efficient operation.
  • Offers broad control compatibility with 24-230V UC control.
  • Supports flexible switching with 24-240V AC and a 1A current rating, designed for DIN rail mounting.

Ensure reliable performance and easy integration with this advanced Weidmuller solid-state relay.

Product Specification

Brand:
Weidmuller
Type:
Solid State Relay
Width:
6.4 mm
Colour:
Black
Length:
87.8 mm
Wattage:
550 mW @ 230 V DC;1.1 VA @ 230 V AC
Frequency:
3 Hz
IP Rating:
IP20
Test Button:
No
Coil Voltage:
24 to 230 V AC/DC
Model/Series:
TOS
Release Time:
Mounting Type:
DIN Rail Mount
Rated Current:
1 A
Rated Voltage:
24 to 240 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;DNV;UKCA;RoHS;UL
Conductor Type:
Rigid Copper Conductor;Flexible Copper Conductor
Operating Time:
Connection Type:
Screw
Control Voltage:
24 to 230 V AC/DC
Status Indicator:
Yes
Number of Contacts:
1
Contact Configuration:
1NO
Protective Circuit Type:
Rectifier
Rated Switching Current:
1 A
Rated Switching Voltage:
24 to 240 V AC
Max Operating Temperature:
+60 °C
Min Operating Temperature:
-20 °C
Height:
89.6 mm
Weight:
34 g
Model Part Code:
TOS 24-230VUC 230VAC1A

Product Downloads

Datasheet
