Weidmuller TFIS On-Delay Timing Relay, 24-240V AC/DC Input, 250V AC/6A Output, 1 Changeover Contact, with LED

PART NO: 2697280000 / SKU: 1035499
Weidmuller TFIS On-Delay Timing Relay, 24-240V AC/DC Input, 250V AC/6A Output, 1 Changeover Contact, with LED
$122.63
inc. GST
$111.48
ex. GST
Free shipping on orders over $100

Explore the high-performance Weidmuller TFIS On-Delay Timing Relay (2697280000), designed for precise control in various applications.

  • Features a wide input voltage range of 24-240V AC/DC.
  • Provides a robust 250V AC/6A output with 1 changeover contact.
  • Equipped with an LED indicator for clear status visualization.

Ensure reliable and efficient timing operations with this advanced Weidmuller timing relay.

Product Specification

Brand:
Weidmuller
Type:
Timer Relay
Width:
17.5 mm
Colour:
Black
Length:
60 mm
Wattage:
1.5 W
Function:
On-Delay Timer
IP Rating:
IP20
Test Button:
No
Model/Series:
TFI
Mounting Type:
TS35 Rail Mount
Rated Current:
8 A
Rated Voltage:
300 V
Terminal Type:
Screw
Certifications:
CE;cULus;RoHs
Connection Type:
Screw
Control Voltage:
24 to 240 V AC/DC
Contact Material:
AgNi
Delay Time Range:
0.05 to 1 s;0.5 to 10 s;3 to 60 s;30 s to 10 min;3 min to 1 h;30 min to 10 h;5 to 100 h
Status Indicator:
Yes
Number of Contacts:
1
Operational Format:
On-Delay;Off-Delay
Contact Configuration:
1CO
Max Operating Temperature:
+55 °C
Min Operating Temperature:
-25 °C
Height:
87 mm
Weight:
69 g
Model Part Code:
TFIS 24-240VUC 1CO ON

Product Downloads

Datasheet
