Weidmuller TFIS Off-Delay Timing Relay, SPDT, 24-240V UC, 8A, Screw Connection, TS35 DIN Rail Mount

PART NO: 2697290000 / SKU: 1035477
Weidmuller TFIS Off-Delay Timing Relay, SPDT, 24-240V UC, 8A, Screw Connection, TS35 DIN Rail Mount
$122.63
inc. GST
$111.48
ex. GST
Free shipping on orders over $100

Explore the Weidmuller TFIS Off-Delay Timing Relay (2697290000), a versatile solution for precise timing applications.


  • Features an off-delay timing function for controlled system shutdowns.
  • Equipped with SPDT contacts, suitable for a wide range of switching tasks.
  • Designed for TS35 DIN rail mount with secure screw connections for easy installation.

Ensure reliable and controlled operations with this robust Weidmuller timing relay.

Product Specification

Brand:
Weidmuller
Type:
Timer Relay
Width:
17.5 mm
Colour:
Black
Length:
60 mm
Wattage:
4 VA;1.5 W
Function:
Off-Delay Timing
IP Rating:
IP20
Test Button:
No
Model/Series:
TFI
Mounting Type:
Chassis Mount
Rated Current:
8 A
Rated Voltage:
250 V AC
Terminal Type:
Screw
Certifications:
CE;cULus;RoHS
Connection Type:
Screw
Control Voltage:
24 to 240 V AC/DC
Contact Material:
AgNi
Delay Time Range:
0.05 to 1 sec;0.5 to 10 sec;3 to 60 sec;30 sec to 10 min;3 min to 1 hr;30 min to 10 hr;5 to 100 hr
Status Indicator:
Yes
Number of Contacts:
1
Operational Format:
Off-Delay
Contact Configuration:
1CO
Max Operating Temperature:
+55 °C
Min Operating Temperature:
-25 °C
Height:
87 mm
Weight:
71 g
Model Part Code:
TFIS 24-240VUC 1CO OFFC

Product Downloads

Datasheet
