Raytec SPZ Hazardous Area LED Flood Light, 6000K, 120°x120° Beam, 110-254V AC, 68W, ATEX/IECEx, Zone 2/22

PART NO: SPZ-FL24-W-120120 / SKU: 1030154
Raytec SPZ Hazardous Area LED Flood Light, 6000K, 120°x120° Beam, 110-254V AC, 68W, ATEX/IECEx, Zone 2/22

Contact Us For Pricing

Pricing for this product is not available online. Please contact us for more details and purchasing options.

Contact Us
Free shipping on orders over $100
$1,529.00
inc. GST
$1,390.00
ex. GST
Free shipping on orders over $100

Discover the Raytec SPZ Hazardous Area LED Flood Light (SPZ-FL24-W-120120), a high-performance lighting solution designed for demanding environments.

  • Features a 6000K color temperature for clear and bright illumination.
  • Offers a wide 120°x120° beam for extensive coverage.
  • ATEX/IECEx certified for Zone 2/22 hazardous areas, ensuring safety and compliance.

Experience superior illumination and safety with this robust Raytec LED flood light.

Product Specification

Brand:
Raytec
Type:
Flood Light
Width:
215 mm
Colour:
Silver
Length:
291 mm
Wattage:
68 W
IK Rating:
IK07
IP Rating:
IP66;IP67
Beam Angle:
120 ° x 120 °
Lumen Output:
9300 lm
Model/Series:
FL24
Power Supply:
Mains
Lens Material:
Toughened Glass
Mounting Type:
U Bracket Mount
Rated Voltage:
110 to 254 V AC
Certifications:
ATEX;IEC Ex;UKEX;CML17ATEX4231;IEC Ex CML 17.0135
IECEx Gas Zone:
Zone 2
Connection Type:
M20
IECEx Dust Zone:
Zone 22
Emergency Backup:
No
Housing Material:
Aluminium
Colour Temperature:
6000 K
Max Operating Temperature:
+55 °C
Min Operating Temperature:
-50 °C
Height:
312 mm
Weight:
8 kg

Warranty Information

5 Years

Product Downloads

Datasheet
