Microsonic mic+35 Ultrasonic Sensor, M30, 65-600mm Range, 2x PNP NO/NC, 9-30V DC, LED Display, M12 Connector

PART NO: mic+35/DD/TC / SKU: 1006438
Microsonic mic+35 Ultrasonic Sensor, M30, 65-600mm Range, 2x PNP NO/NC, 9-30V DC, LED Display, M12 Connector
$577.50
inc. GST
$525.00
ex. GST
Free shipping on orders over $100

Discover the advanced capabilities of the Microsonic mic+35 Ultrasonic Sensor (mic+35/DD/TC).

  • Features a 65-600mm range for precise distance measurement.
  • Equipped with 2x PNP NO/NC outputs for flexible integration.
  • Operates on 9-30V DC and includes an LED display and M12 connector for easy setup.

Experience reliable and accurate sensing with this versatile ultrasonic sensor from Microsonic.

Product Specification

Brand:
Microsonic
Type:
Ultrasonic Sensor
Style:
M30
Length:
84 mm
Accuracy:
±1 %
Function:
Proximity
IP Rating:
IP67
Resolution:
0.025 mm
Output Type:
PNP
Model/Series:
mic+
Rated Current:
80 mA
Sensing Range:
65 to 600 mm
Certifications:
UL
Connection Type:
M12
Output Function:
NO/NC
Housing Material:
Brass Sleeve;Plastic Parts;PBT;TPU
Input Signal Type:
Synchronization
Operating Voltage:
9 to 30 V DC
Display Technology:
LED
Switching Frequency:
400 kHz
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Weight:
150 g

Product Downloads

Datasheet
