Microsonic mic+25 Ultrasonic Sensor, M30, 30-350mm Range, Analog 4-20mA/0-10V Output, 9-30V DC, LED Display

PART NO: mic+25/IU/TC / SKU: 1006424
Microsonic mic+25 Ultrasonic Sensor, M30, 30-350mm Range, Analog 4-20mA/0-10V Output, 9-30V DC, LED Display
$748.00
inc. GST
$680.00
ex. GST
Free shipping on orders over $100

Discover the Microsonic mic+25 Ultrasonic Sensor (mic+25/IU/TC), a highly versatile solution for precise distance measurement.

  • Features a 30-350mm range for a variety of applications.
  • Offers both analog 4-20mA and 0-10V output for flexible integration.
  • Equipped with a clear LED display and operates on 9-30V DC.

Achieve reliable and accurate sensing in your systems with this advanced ultrasonic sensor.

Product Specification

Brand:
Microsonic
Type:
Ultrasonic Sensor
Style:
M30
Length:
84 mm
Accuracy:
±1 %
Function:
Analogue Distance Measurements
IP Rating:
IP67
Resolution:
0.025 to 0.10 mm
Application:
Industrial
Output Type:
Analogue
Model/Series:
mic+
Rated Current:
80 mA
Sensing Range:
30 to 350 mm
Certifications:
UL
Connection Type:
M12
Housing Material:
Brass Sleeve;Plastic Parts;PBT;TPU
Input Signal Type:
Synchronization
Operating Voltage:
9 to 30 V DC
Display Technology:
LED
Switching Frequency:
320 kHz
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Weight:
150 g

Product Downloads

Datasheet
