Kubler 5000 Incremental Encoder, 10mm Shaft, 50mm Diameter, 1000 PPR, Push-Pull, 10-30VDC, M12 Connector

PART NO: 8.5000.7354.1000 / SKU: 1018860
Kubler 5000 Incremental Encoder, 10mm Shaft, 50mm Diameter, 1000 PPR, Push-Pull, 10-30VDC, M12 Connector
$704.29
inc. GST
$640.26
ex. GST
Free shipping on orders over $100

Explore the Kubler 5000 Incremental Encoder (8.5000.7354.1000), a robust solution for reliable rotary encoding applications.

  • Features a 10mm shaft and 50mm diameter for versatile integration.
  • Offers 1000 PPR (Pulses Per Revolution) for precise measurement.
  • Equipped with Push-Pull output and 10-30VDC power supply, with an M12 Connector for easy installation.

Ensure superior accuracy and operational integrity with this advanced Kubler incremental encoder.

Product Specification

Brand:
Kubler
Type:
Incremental
Diameter:
58
IP Rating:
IP67
Shaft Size:
10 mm
Shaft Type:
Standard Shaft
Model/Series:
5000
Certifications:
Ex 2/22;cULus;RoHS
Interface Type:
Push-Pull
Max Resolution:
1000 pixel
Rotation Speed:
6000 rpm
Supply Voltage:
10 to 30 V DC
Connection Type:
M12
Measurement Type:
Optical
Output Signal Type:
Push Pull
Pulses per Resolution:
1000 PPR
Max Operating Temperature:
+85 °C
Min Operating Temperature:
-40 °C
Height:
94 mm
Weight:
400 g

Product Downloads

Datasheet
