Bernstein AG SRM Safety Rope Pull Switch, 2NC/2NO, 10A, 240V, Metal Enclosure, 37.5m Span, Emergency Stop

PART NO: 6012929085 / SKU: 1038101
Bernstein AG SRM Safety Rope Pull Switch, 2NC/2NO, 10A, 240V, Metal Enclosure, 37.5m Span, Emergency Stop
$313.50
inc. GST
$285.00
ex. GST
Free shipping on orders over $100

Discover the Bernstein AG SRM Safety Rope Pull Switch (6012929085), a robust solution for reliable safety applications.

  • Equipped with 2NC/2NO contacts and a 10A, 240V rating for versatile power compatibility.
  • Features a durable metal enclosure for enhanced protection in demanding environments.
  • Offers a 37.5m span and an emergency stop function for superior safety and operational integrity.

Ensure superior safety and operational integrity with this advanced Bernstein AG safety rope pull switch.

Product Specification

Brand:
Bernstein
Type:
Rope Pull Switch
Class:
Class I
Width:
53 mm
Length:
90 mm
Assembled:
Yes
IP Rating:
IP67
Entry Type:
M20
Button Type:
Emergency Stop Button
Orientation:
Straight
Model/Series:
SRM
Actuator Type:
Quick Clamping
Rated Current:
10 A
Rated Voltage:
240 V
Remote Signal:
Wireless
Certifications:
DIN EN 60947-1;IEC 60947-1;DIN EN 60947-5-1;IEC 60947-5-1;DIN EN 60947-5-5;IEC 60947-5-5;ISO 13850;DIN EN ISO 13849-1;DGUV;CCC;CSAus
Connection Type:
Screw
Max Rope Length:
37.5 m
Cable Entry Size:
3 x M20 x 1.5
Housing Material:
Die Cast Aluminium
Rope Connection Type:
Quick Fix
Contact Configuration:
2NO/2NC
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Depth:
282 mm
Weight:
1 kg

Product Downloads

Datasheet
