Bernstein AG SK Interlock Safety Switch, 1NO/1NC, 10A, 250V AC, Plastic Body, 3x M20 Cable Entry, IP65

PART NO: 6016119181 / SKU: 1039835
Bernstein AG SK Interlock Safety Switch, 1NO/1NC, 10A, 250V AC, Plastic Body, 3x M20 Cable Entry, IP65
$67.10
inc. GST
$61.00
ex. GST
Free shipping on orders over $100

Discover the Bernstein AG SK Interlock Safety Switch, part number 6016119181. This essential safety component provides secure interlocking for various applications.


• Equipped with 1NO/1NC contacts for flexible integration.
• Handles up to 10A at 250V AC, ensuring reliable performance.
• Features a durable plastic body and 3x M20 cable entries for easy installation, with an IP65 rating for protection.


Upgrade your safety systems with this high-quality Bernstein AG switch.

Product Specification

Brand:
Bernstein
Type:
Safety Interlock Switch
Class:
Class II
Width:
33 mm
Length:
52 mm
IP Rating:
IP65
Entry Type:
3 x M20
Title Plate:
Yes
Model/Series:
SK
Rated Current:
10 A
Rated Voltage:
240 V
Certifications:
DIN EN 60947-5-1;DIN EN ISO 13849-1;DIN EN ISO 14119;cCSAus;CCC
Connection Type:
M20
Housing Material:
Polyamide
Wire Cross Section:
0.5 to 1.5 mm²
Contact Configuration:
1NO/1NC
Number of Connections:
6
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Height:
90 mm
Weight:
120 g

Product Downloads

Datasheet
