Product Specification
Brand:
Balluff
Type:
Inductive Sensor
Style:
40 x 40
Width:
40 mm
Length:
40 mm
Frequency:
50 Hz
IP Rating:
IP67
Application:
Industrial
Output Type:
NPN
Rated Current:
200 mA
Sensing Range:
20 mm
Certifications:
CE;UKCA;cULus;WEEE
Connection Type:
M12
Output Function:
NO/NC
Housing Material:
PBT
Installation Type:
Flush Mount
Operating Voltage:
10 to 55 V DC
Sensing Surface Material:
PBT
Max Operating Temperature:
+70 °C
Min Operating Temperature:
-25 °C
Height:
40 mm
Weight:
250 g
Model Part Code:
BES Q40KEU-NAH20B-S04G-001
Warranty Information
12 Months
