Bernstein AG SID Rope Pull Switch, 2NC/2NO, 16A, 240V, Metal Enclosure, Blue Push Button Reset, IP65

PART NO: 6012441907 / SKU: 1023983
Bernstein AG SID Rope Pull Switch, 2NC/2NO, 16A, 240V, Metal Enclosure, Blue Push Button Reset, IP65
$375.10
inc. GST
$341.00
ex. GST
Free shipping on orders over $100

Discover the Bernstein AG SID Rope Pull Switch (6012441907), a robust solution for industrial safety applications.

  • Equipped with 2NC/2NO contacts and a 16A, 240V rating for versatile power compatibility.
  • Features a durable metal enclosure for enhanced protection and longevity.
  • Includes a blue push button reset and an IP65 rating for reliable operation in demanding environments.

Ensure superior safety and operational integrity with this advanced Bernstein AG rope pull switch.

Product Specification

Brand:
Bernstein
Type:
Rope Pull Switch
Class:
Class I
Width:
68 mm
Length:
82 mm
Assembled:
Yes
IP Rating:
IP65
Entry Type:
M20
Button Type:
Push Button
Orientation:
Straight
Model/Series:
SiD
Actuator Type:
Pull Ring
Rated Current:
16 A
Rated Voltage:
240 V
Remote Signal:
Wireless
Certifications:
VDE 0660 T100;DIN EN 60947-1;IEC 60947-1;VDE 0660 T200;DIN EN 60947-5-1;IEC 60947-5-1;DIN EN ISO 13849-1;cCSAus;UL;CCC
Connection Type:
Screw
Cable Entry Size:
2 x M20 x 1.5
Housing Material:
Die Cast Aluminium
Rope Connection Type:
Eyelet
Contact Configuration:
2NO/2NC
Max Operating Temperature:
+80 °C
Min Operating Temperature:
-30 °C
Depth:
196 mm
Weight:
610 g

Product Downloads

Datasheet
